DRYER FABRICS

MonoTier Concept


	MonoTier Concept
	S-4 HP
	MonoTier warp loop seam made out of untwisted flat ribbons




	S-47 HP
	Warp loop seam with integrated hydrolysis resistant PEEK-spiral.




	S-47 k
	Finer warp loop seam with integrated hydrolysis resistant PEEK-spiral in the air permeability range 400-700 cfm.




	S-43 k
	Finer warp loop seam with integrated PET-spiral in the air permeability range 400-700 cfm.

Conventional


	Conventional Dryer Fabrics
	S-4
		Warp loop seam



	S-47
		Warp loop seam with integrated hydrolysis resistant PEEK-spiral.

Product Overview



	1.A MONOTIER CONCEPT DRYER FABRICS
	MonoTier II R MonoTier II R-6 UltraClean R MonoTec MonoTier III R MonoTier III R 150 MonoTier III R-6 MonoTier III R-6 Plus UltraTier II UltraTier III UltraTemp 120-200 UltraTemp 250-400

	1.B SMART SURFACE TECHNOLOGY
	MicroTec II MicroTec II -6 CleanTec II SpeedTec II

	1.C CONVENTIONAL DRYER FABRICS
	Monosoft

	1.D SPIRAL FABRICS
	SpiralTec SpiralFine SpiralPro 1000 SpiralDry 1000

	1.E TRANSPORT FABRICS
	TransporTier III C TransporTier III CS


	1.F SEAM DESIGNS
	Seam Designs for MonoTier Concept Dryer Fabrics
	- S-4 HP
	- S-47 HP
	- S-47 k
	- S-43 k

	Seam Designs for Conventional Fabrics
	- S-4
	- S-47

	Seam Designs for Transport Fabrics
	- S-UM / S-UP
	- S-IC

	Table of Joining Wire Diameters Table of seam strength

	1.G EQUIPMENT
	Poles Packaging Joining Wires SAF-T-JOIN
	Filling Wires Leader Skirt SAF-T-LOOP
	Seaming Aids
	- SPEED-O-MAT
	- AST-O-MAT 6
	- AST-O-MAT 15
	- AST-O-MAT 30
	Coloured Steel Wire Tip Seaming Tool
	Chemical Equipment
	- ArmorTec
	Stripes in Contrasting Colours Edge Protections
	- ProLine S
	- ProTec S
	Ceran II
	- HMC
	- PU
	- VR
	Hydrolysis Resistant Edge Reinforcement

Product Line 60-110



	cfm	60	70	80	90	100	110
	m/h	1000	1150	1300	1450	1650	1800
Technology	Product name	AIR PERMEABILITY
MonoTier Concept	MonoTier II R	s		X		X	X
	MonoTier II R-6						X
	MonoTier II R-6 Plus						s
	PermaLife II (W)					s
	MonoTec			X		X	X
	MonoTier III R					s	s
	MonoTier III R-6 (Plus)
	UltraClean R			X		X	X
	UltraTier II
	UltraTier II-6
	UltraTier III
	UltraTier III-6
	UltraTemp
	UltraTemp P12, P25, P50
Smart Surface Technology	MicroTec II			X		X	X
	MicroTec II-6
	MicroTec II-6 Plus
	CleanTec II						X
	SpeedTec II						X
	MagnaTec						s
Conventional Dryer Fabrics	Monosoft		X		X		X
	MonoPro 33					s
	MonoPro HTR
	MonoTop HTR
Spiral Fabrics	SpiralTec						X
	SpiralFine				s		X
	SpiralPro
	SpiralDry
	SpiralTemp
	Design Type	X = STANDARD S = SPECIAL

Product Line 120-350



	cfm	120	150	200	250	300	350
	m/h	1950	2450	3300	4100	4900	5700
Technology	Product name	AIR PERMEABILITY
MonoTier Concept	MonoTier II R	X	X	X
	MonoTier II R-6	X	X	X
	MonoTier II R-6 Plus	s	s	s
	PermaLife II (W)	s	s	s
	MonoTec	X	X	X	X	X
	MonoTier III R	s	X	X	X	X	X
	MonoTier III R-6 (Plus)		X	X	X	X	X
	UltraClean R	X	X	X
	UltraTier II			X	X	X
	UltraTier II-6				s	s
	UltraTier III
	UltraTier III-6
	UltraTemp	X	X	X	X	X
	UltraTemp P12, P25, P50	s	s	s	s	s
Smart Surface Technology	MicroTec II	X	X	X	X	X
	MicroTec II-6	X	X	X	X	X
	MicroTec II-6 Plus	s	s	s	s	s
	CleanTec II	X	X	X	X	X	X
	SpeedTec II	X	X	X
	MagnaTec		s
Conventional Dryer Fabrics	Monosoft
	MonoPro 33				s
	MonoPro HTR
	MonoTop HTR
Spiral Fabrics	SpiralTec		X	X		X
	SpiralFine		X	X		X
	SpiralPro		s	s	X
	SpiralDry
	SpiralTemp
	Design Type	X = STANDARD S = SPECIAL

Product Line 400-1000



	cfm	400	500	550	600	700	800	1000
	m/h	6500	8200	9800	9000	11400	13100	16300
Technology	Product name	AIR PERMEABILITY
MonoTier Concept	MonoTier II R
	MonoTier II R-6
	MonoTier II R-6 Plus
	PermaLife II (W)
	MonoTec	X
	MonoTier III R	X	X	X	X	s
	MonoTier III R-6 (Plus)	X	X	X	X	s
	UltraClean R
	UltraTier II	X
	UltraTier II-6	s
	UltraTier III		X	X	X	s
	UltraTier III-6		s	s	s	s
	UltraTemp	X
	UltraTemp P12, P25, P50	s
Smart Surface Technology	MicroTec II	X
	MicroTec II-6	X
	MicroTec II-6 Plus	s
	CleanTec II
	SpeedTec II
	MagnaTec
Conventional Dryer Fabrics	Monosoft
	MonoPro 33	s	s
	MonoPro HTR		s
	MonoTop HTR			s			s
Spiral Fabrics	SpiralTec	X
	SpiralFine	X						s
	SpiralPro	s						X
	SpiralDry		s			s		X
	SpiralTemp	s	s			s		s
	Design Type	X = STANDARD S = SPECIAL

Single Warp Systems

0.50 mm

MagnaTec

Monosoft

MonoPro 33

MonoPro HTR

MonoTop HTR

0.38 mm

SpiralFine

0.40 mm

SpiralTec

0.60 mm

SpiralPro

SpiralTemp

0.70 mm

SpiralDry

Dual Warp Systems

PS: 0.25 mm / MS: 0.25 mm

MonoTier II R

PermaLife II

UltraClean R

PS: 0.30 mm / MS: 0.30 mm

MicroTec II

CleanTec II

SpeedTec II

UltraTier II

UltraTemp

PS: 0.36 mm / MS: 0.36 mm

MonoTier III R

UltraTier III

MonoTier II R



BASIC INFORMATION
Technology	MonoTier
STYLE	MonoTier II R
Construction	monofilament / flat ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics



PROPERTIES
Air Perm (cfm)	80	100	110	120	150	200
Air Perm (m/h)	1300	1650	1800	1950	2450	3300
C_A Value	1.1	1.3	1.35	1.4	1.6	1.8
Contact Area (%)	58
Caliper (mm)	1.45	1.45	1.4	1.4	1.3	1.3
Weight (g/m²)	1350	1300	1250	1200	1100	1000
MD TS - edge / center (daN/10 cm)	1900

MATERIALS
MD [edge/center]	PET
CMD	PET
% PET [edge/center]	100
% PPS [edge/center]
% PAN

SEAMS
Standard Seam	S-4 HP
Characteristics	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional Seam designs


EDGE TREATMENTS
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSISTS
Standard Assist	Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#	#	#
Ast-o-mat 15	#	#	#	#	#	#
Ast-o-mat 30			#	#	#	#
# for all seam designs available on this fabric design

MonoTier II R-6



BASIC INFORMATION
Technology	MonoTier
STYLE	MonoTier II R-6
Construction	monofilament / flat ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics	PPS edge reinforcement 100% on paper side. Standard width: 30 cm (only available on fabrics with a width ≥ 3 m).




PROPERTIES
Air Perm (cfm)	110	120	150	200
Air Perm (m/h)	1800	1950	2450	3300
C_A Value	1.4	1.4	1.60	1.8
Contact Area (%)	58
Caliper (mm)	1.40	1.40	1.3	1.3
Weight (g/m²)	1250	1200	1100	1000
MD TS - edge / center (daN/10 cm)	1400/1900

MATERIALS
MD [edge/center]	PET+PPS/PET
CMD	PET
% PET [edge/center]	65/100
% PPS [edge/center]	35/0
% PAN

SEAMS
Standard Seam	S-4 HP
Characteristics	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional Seam designs


EDGE TREATMENTS
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSISTS
Standard Assist	Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#
Ast-o-mat 15	#	#	#	#
Ast-o-mat 30	#	#	#	#
# for all seam designs available on this fabric design

MonoTier III R

BASIC INFORMATION

Technology

MonoTier

STYLE

MonoTier III R

Construction

monofilament / micro structured ribbon

MD Layer / Warp System

2 / separated

CMD Layers

Characteristics

Improved wear resistance.

PROPERTIES

Air Perm (cfm)

150

200

250

300

350

400

500

550

600

Air Perm (m/h)

2450

3300

4100

4900

5700

6500

8200

9000

9800

C_A Value

2.0

2.1

2.3

2.5

3.0

3.2

3.3

3.4

Contact Area (%)

Caliper (mm)

1.85

1.8

Weight (g/m²)

1500

1400

1350

1300

1250

1200

1150

1125

1100

MD TS - edge / center (daN/10 cm)

2200

1900

MATERIALS

MD [edge/center]

PET

CMD

PET/PET
multifilament

PET

% PET [edge/center]

100

% PPS [edge/center]

% PAN

SEAM DESIGN

Standard Seam

S-4 HP

S-47 HP

Characteristics

S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional designs

S-43 k for making sensitive
positions.

EDGE TREATMENT

Standard Treatment

ProLine S

Optional Treatments

Ceran II, ProTec S

SEAM ASSIST

Standard Assist

Speed-o-mat

Optional Assists

Ast-o-mat 6

Ast-o-mat 15

Ast-o-mat 30

# for all seam designs available on this fabric design

MonoTier III R-6



BASIC INFORMATION
Technology	MonoTier
STYLE	MonoTier III R-6
Construction	monofilament / micro structured ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics	Improved wear resistance. PPS edge reinforcement 100 % on paper side. Standard width : 30 cm. Only available on fabrics with a width ≥ 3 m.



PROPERTIES
Air Perm (cfm)	150	200	250	300	350	400	500	550	600
Air Perm (m/h)	2450	3300	4100	4900	5700	6500	8200	9000	9800
C_A Value	2.0	2.0	2.1	2.3	2.5	3.0	3.2	3.3	3.4
Contact Area (%)	42	45					34
Caliper (mm)	1.85	1.8					1.8
Weight (g/m²)	1400	1400	1350	1300	1250	1200	1150	1125	1100
MD TS - edge / center (daN/10 cm)	1650 / 2200	1650 / 2200					1300 / 1900

MATERIALS
MD - Edge	PET + PPS	PET + PPS					PET + PPS
MD - Center	PET	PET					PET
CMD - Edge	PET/PET multi	PET					PET
CMD - Center	PET/PET multi	PET					PET
% PET [edge/center]	68/100	68/100					68/100
% PPS [edge/center]	32/0	32/0					32/0
% PAN

SEAM DESIGN
Standard Seam	S-4 HP	S-4 HP					S-47 HP
Characteristics	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional designs							S-43 k for making sensitive positions.
							S-43 k for making sensitive positions.

EDGE TREATMENT
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSIST
Standard Assist	Speed-o-mat						Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#	#	#	#	#	#
Ast-o-mat 15	#	#	#	#	#	#	#	#	#
Ast-o-mat 30	#	#	#	#	#	#	#	#	#
# for all seam designs available on this fabric design

MonoTier III R-6 Plus

BASIC INFORMATION

Technology

MonoTier

STYLE

MonoTier III R-6 Plus

Construction

monofilament / micro structured ribbon

MD Layer / Warp System

2 / separated

CMD Layers

Characteristics

Improved wear resistance.
PPS edge reinforcement 100 % on paper side.
Standard width : 30 cm. Only available on fabrics with a width ≥ 3 m.
The binding weft is also made out of PPS.

PROPERTIES

Air Perm (cfm)

150

200

250

300

350

400

500

550

600

Air Perm (m/h)

2450

3300

4100

4900

5700

6500

8200

9000

9800

C_A Value

2.0

2.1

2.3

2.5

3.0

3.2

3.3

3.4

Contact Area (%)

Caliper (mm)

1.85

1.80

1.8

Weight (g/m²)

1500

1450

1350

1300

1250

1150

1125

1100

MD TS - edge / center (daN/10 cm)

1650/2200

1300/1900

MATERIALS

MD - Edge

PET + PPS

MD - Center

PET

CMD - Edge

PET/PET
multi

PET / PPS

CMD - Center

PET/PET
multi

PET / PPS

% PET [edge/center]

58 / 85

% PPS [edge/center]

42 / 15

% PAN

SEAM DESIGN

Standard Seam

S-4 HP

S-47 HP

Characteristics

S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional designs

S-43 k for making sensitive
positions.

EDGE TREATMENT

Standard Treatment

ProLine S

Optional Treatments

Ceran II, ProTec S

SEAM ASSIST

Standard Assist

Speed-o-mat

Optional Assists

Ast-o-mat 6

Ast-o-mat 15

Ast-o-mat 30

# for all seam designs available on this fabric design

MicroTec II



BASIC INFORMATION
Technology	MonoTier
STYLE	MicroTec II
Construction	monofilament / micro structured ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics	Streamlined fabric surface and ideal contamination management through longitudinal grooves. Increased wear volume



PROPERTIES
Air Perm (cfm)	80	100	110	120	150	200	250	300	400
Air Perm (m/h)	1300	1650	1800	1950	2450	3300	4100	4900	6500
C_A Value
Contact Area (%)	40						28
Caliper (mm)	1.65	1.65	1.5	1.5	1.4	1.4	1.55	1.55	1.55
Weight (g/m²)	1350	1300	1250	1200	1100	1050	1150	1100	1000
MD TS - edge / center (daN/10 cm)	2100						1750

MATERIALS
MD [edge/center]	PET
CMD	PET
% PET [edge/center]	100
% PPS [edge/center]
% PAN

SEAM DESIGN
Standard Seam	S-4 HP						S-47 HP
Characteristics	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional designs


EDGE TREATMENT
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSIST
Standard Assist	Speed-o-mat						Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#	#	#	#	#	#
Ast-o-mat 15	#	#	#	#	#	#	#	#	#
Ast-o-mat 30			#	#	#	#	#	#	#
# for all seam designs available on this fabric design

MicroTec II-6



BASIC INFORMATION
Technology	MonoTier
STYLE	MicroTec II
Construction	monofilament / micro structured ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics	Streamlined fabric surface and ideal contamination management through longitudinal grooves. Increased wear volume



PROPERTIES
Air Perm (cfm)	80	100	110	120	150	200	250	300	400
Air Perm (m/h)	1300	1650	1800	1950	2450	3300	4100	4900	6500
C_A Value
Contact Area (%)	40						28
Caliper (mm)	1.65	1.65	1.5	1.5	1.4	1.4	1.55	1.55	1.55
Weight (g/m²)	1350	1300	1250	1200	1100	1050	1150	1100	1000
MD TS - edge / center (daN/10 cm)	2100						1750

MATERIALS
MD [edge/center]	PET
CMD	PET
% PET [edge/center]	100
% PPS [edge/center]
% PAN

SEAM DESIGN
Standard Seam	S-4 HP						S-47 HP
Characteristics	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional designs


EDGE TREATMENT
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSIST
Standard Assist	Speed-o-mat						Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#	#	#	#	#	#
Ast-o-mat 15	#	#	#	#	#	#	#	#	#
Ast-o-mat 30			#	#	#	#	#	#	#
# for all seam designs available on this fabric design

UltraClean R



BASIC INFORMATION
Technology	MonoTier
STYLE	UltraClean R
Construction	monofilament / flat ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics	Paper side covered with 100 % PET with a dirt repellent additive (SPET).




PROPERTIES
Air Perm (cfm)	80	100	120	150	200
Air Perm (m/h)	1300	1650	1950	2450	3300
C_A Value	1.1	1.3	1.40	1.6	1.8
Contact Area (%)	58
Caliper (mm)	1.45	1.45	1.4	1.3	1.3
Weight (g/m²)	1350	1300	1200	1100	1000
MD TS - edge / center (daN/10 cm)	1900

MATERIALS
MD [edge/center]	SPET/PET
CMD	PET
% PET [edge/center]	65/100
% PPS [edge/center]	35/0
% PAN

SEAMS
Standard Seam	S-4 HP
Characteristics	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional Seam designs


EDGE TREATMENTS
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSISTS
Standard Assist	Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#
Ast-o-mat 15	#	#	#	#
Ast-o-mat 30		#	#	#
# for all seam designs available on this fabric design

MonoTec



BASIC INFORMATION
Technology	MonoTier
STYLE	MonoTec
Construction	monofilament / flat ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics	MonoTier weave pattern. Fabric with improved wear resistance in low and mid perm and high contact area.



PROPERTIES
Air Perm (cfm)	80	100	110	120	150	200	250	300	400
Air Perm (m/h)	1300	1650	1800	1950	2450	3300	4100	4900	6500
C_A Value	1.1	1.3	1.40	1.4	1.6	1.8
Contact Area (%)	58						45
Caliper (mm)	1.70	1.70	1.7	1.7	1.5	1.5	1.50	1.50	1.5
Weight (g/m²)	1350	1300	1250	1200	1100	1050	1150	1100	1000
MD TS - edge / center (daN/10 cm)	1900						1650

MATERIALS
MD [edge/center]	PET
CMD	PET
% PET [edge/center]	100
% PPS [edge/center]
% PAN

SEAM DESIGN
Standard Seam	S-4 HP						S-47 HP
Characteristics	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional designs


EDGE TREATMENT
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSIST
Standard Assist	Speed-o-mat						Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#	#	#	#	#	#
Ast-o-mat 15	#	#	#	#	#	#	#	#	#
Ast-o-mat 30			#	#	#	#	#	#	#
# for all seam designs available on this fabric design

UltraTier II



BASIC INFORMATION
Technology	MonoTier
STYLE	UltraTier II
Construction	monofilament / flat ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics	Increased wear volume The paper side is 100 % hydrolysis resistant. The binding weft is also made out of PPS.




PROPERTIES
Air Perm (cfm)	200	250	300	400
Air Perm (m/h)	3300	4100	4900	6500
C_A Value	1.8	2.2	2.40
Contact Area (%)	45
Caliper (mm)	1.55
Weight (g/m²)	1000	1150	1100	1000
MD TS - edge / center (daN/10 cm)	1300

MATERIALS
MD [edge/center]	PPS/PET
CMD	PPS/PET
% PET [edge/center]	56
% PPS [edge/center]	44
% PAN

SEAMS
Standard Seam	S-47 HP
Characteristics	S-47 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional Seam designs	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.


EDGE TREATMENTS
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSISTS
Standard Assist	Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#
Ast-o-mat 15	#	#	#	#
Ast-o-mat 30		#	#	#
# for all seam designs available on this fabric design

CleanTec II



BASIC INFORMATION
Technology	Smart Surface
STYLE	CleanTec II
Construction	monofilament / micro structured ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics	Structured fabric surface for ideal contamination management through longitudinal grooves and a high amount of small contact points. Increased wear volume



PROPERTIES
Air Perm (cfm)	110	120	150	200	250	300	350
Air Perm (m/h)	1800	1950	2450	3300	4100	4900	5700
C_A Value
Contact Area (%)	18				18
Caliper (mm)	1.65				1.55
Weight (g/m²)	1200	1150	1100	1050	1000	980	950
MD TS - edge / center (daN/10 cm)	1800				1600

MATERIALS
MD - Edge	PET				PET
MD - Center	PET				PET
CMD - Edge	PET				PET
CMD - Center	PET				PET
% PET [edge/center]	100				100
% PPS [edge/center]
% PAN

SEAM DESIGN
Standard Seam	S-4 HP				S-47 HP
Characteristics	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional designs					S-43 k for making sensitive positions.
					S-43 k for making sensitive positions.

EDGE TREATMENT
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSIST
Standard Assist	Speed-o-mat				Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#	#	#	#
Ast-o-mat 15					#	#	#
Ast-o-mat 30					+	+	+
# for all seam designs available on this fabric design + only for S-47 HP

SpeedTec II



BASIC INFORMATION
Technology	Smart Surface
STYLE	SpeedTec II
Construction	monofilament / micro structured ribbon
MD Layer / Warp System	2 / separated
CMD Layers	1
Characteristics	Structured fabric surface for ideal contamination management through longitudinal grooves and a weave structure to reduce speed differences. Increased wear volume



PROPERTIES
Air Perm (cfm)	110	120	150	200
Air Perm (m/h)	1800	1950	2450	3300
C_A Value
Contact Area (%)	30
Caliper (mm)	1.55
Weight (g/m²)	1200	1150	1100	1050
MD TS - edge / center (daN/10 cm)	1950

MATERIALS
MD - Edge	PET
MD - Center	PET
CMD - Edge	PET
CMD - Center	PET
% PET [edge/center]	100
% PPS [edge/center]
% PAN

SEAM DESIGN
Standard Seam	S-4 HP
Characteristics	S-4 HP MonoTier warp loop seam made out of untwisted flat ribbons.

Optional designs


EDGE TREATMENT
Standard Treatment	ProLine S
Optional Treatments	Ceran II, ProTec S

SEAM ASSIST
Standard Assist	Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#	#	#
Ast-o-mat 15	#	#	#	#
Ast-o-mat 30	+	+	+	+
# for all seam designs available on this fabric design + only for S-47 HP

MagnaTec



BASIC INFORMATION
Technology	Smart Surface
STYLE	MagnaTec
Construction	monofilament / micro structured ribbon
MD Layer / Warp System	1 / single
CMD Layers	1
Characteristics	Exceptional high number of contact points and high contact area for improved drying and energy saving. High wear volume for long lifetime. Smart Surface Technology design with structured fabric surface for ideal contamination management. Low void volume - permeability remains on a higher level.




PROPERTIES
Air Perm (cfm)	110	150
Air Perm (m/h)	1800	2450
C_A Value
Contact Area (%)	30
Caliper (mm)	1.55
Weight (g/m²)	1150	1150
MD TS - edge / center (daN/10 cm)	2000

MATERIALS
MD [edge/center]	PET
CMD	PET
% PET [edge/center]	100
% PPS [edge/center]
% PAN

SEAMS
Seam Designs	S-43
	S-47
	S-47 k
Seam Characteristics	S-43 for making sensitive positions.
	S-47 for wear prone positions.
	S-47 k for wear prone and marking sensitive positions.

EDGE TREATMENTS
Standard Treatment	ProTec S
Optional Treatments	ProLine S

SEAM ASSISTS
Standard Assist	Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#
Ast-o-mat 15	#	#
Ast-o-mat 30	#	#
# for all seam designs available on this fabric design

EnerTemp II



BASIC INFORMATION
Technology	MonoLine
STYLE	EnerTemp II
Construction	monofilament / flat ribbon
MD Layer / Warp System	1 / single
CMD Layers	1
Characteristics	• Excellent resistance to heat and hydrolysis degradation for longer life • Monofilament construction provides excellent dimensional stability • Flat machine direction yarns provide good contact for improved drying




PROPERTIES
Air Perm (cfm)	110	150
Air Perm (m/h)	1800	2450
C_A Value
Contact Area (%)	30
Caliper (mm)	1.55
Weight (g/m²)	1150	1150
MD TS - edge / center (daN/10 cm)	2000

MATERIALS
MD [edge/center]	PET
CMD	PET
% PET [edge/center]	100
% PPS [edge/center]
% PAN

SEAMS
Seam Designs	S-43
	S-47
	S-47 k
Seam Characteristics	S-43 for making sensitive positions.
	S-47 for wear prone positions.
	S-47 k for wear prone and marking sensitive positions.

EDGE TREATMENTS
Standard Treatment	ProTec S
Optional Treatments	ProLine S

SEAM ASSISTS
Standard Assist	Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#
Ast-o-mat 15	#	#
Ast-o-mat 30	#	#
# for all seam designs available on this fabric design

Patriot



BASIC INFORMATION
Technology	MonoLine
STYLE	Patriot
Construction	monofilament / flat ribbon
MD Layer / Warp System	1 / single
CMD Layers	1
Characteristics	• Roll side float for Abrasion Resistance • Seam below plane of fabric • Excellent stability properties




PROPERTIES
Air Perm (cfm)	110	150
Air Perm (m/h)	1800	2450
C_A Value
Contact Area (%)	30
Caliper (mm)	1.55
Weight (g/m²)	1150	1150
MD TS - edge / center (daN/10 cm)	2000

MATERIALS
MD [edge/center]	PET
CMD	PET
% PET [edge/center]	100
% PPS [edge/center]
% PAN

SEAMS
Seam Designs	S-43
	S-47
	S-47 k
Seam Characteristics	S-43 for making sensitive positions.
	S-47 for wear prone positions.
	S-47 k for wear prone and marking sensitive positions.

EDGE TREATMENTS
Standard Treatment	ProTec S
Optional Treatments	ProLine S

SEAM ASSISTS
Standard Assist	Speed-o-mat
Optional Assists
Ast-o-mat 6	#	#
Ast-o-mat 15	#	#
Ast-o-mat 30	#	#
# for all seam designs available on this fabric design

SpiralPro



	BASIC INFORMATION
	Technology	SpiralPro
	STYLE	SpiralPro 1000
	Construction	monofilament / round wire spiral fabric
	MD Layer / Warp System	1
	CMD Layers	1
	Characteristics	Medium fine spiral design.




	PROPERTIES
	Air Perm (cfm)	1000
	Air Perm (m/h)	16300
	C_A Value
	Contact Area (%)	25
	Caliper (mm)	2.2
	Weight (g/m²)	1250
	MD TS - edge / center (daN/10 cm)	1900

	MATERIALS
	MD [edge/center]	P{ET
	CMD	PET
	% PET [edge/center]	100
	% PPS [edge/center]	100
	% PAN

	SEAMS
	Standard Seam	EZS
	Characteristics

	Optional Seam designs


	EDGE TREATMENTS
	Standard Treatment	Speed-o-mat
	Optional Treatments	Ceran II, ProTec S

	SEAM ASSISTS
	Standard Assist	Speed-o-mat
	Optional Assists
	Ast-o-mat 6	#
	# for all seam designs available on this fabric design

Join Wire Diameters



MonoTier Concept Fabric Designs
Fabric Design	CFM	S-4 HP	S-47 HP	S-47 k	S-43
MonoTier II R (-6) & UltraClean R, MonoTec	80	0.8	0.7
MonoTier II R (-6), UltraClean R, MonoTec & PermaLife II	100-200	0.7	0.7
MonoTec	250-400	0.8	0.7
MonoTier III R, R-6 & R-6 Plus	150-400	0.8	0.7
MonoTier III R, R-6 & R-6 Plus	500-600		0.7	0.7	0.7
UltraTier II (-6)	200-400	0.8	0.7
UltraTemp	120-400	0.8	0.7
UltraTier III	500-600		0.7	0.7	0.7

Smart Surface Technology Fabric Designs
Fabric Design	CFM	S-4 HP	S-47 HP	S-47 k	S-43
MicroTec II	80	0.8	0.7
MicroTec II, II-6	120-200	0.7	0.7
MicroTec II, II-6	250-400	0.8	0.7
CleanTec II	110-350	0.7	0.7
SpeedTec II	110-200	0.7	0.7
MagnaTec	110-150		0.6	0.6	0.6

Conventional Fabric Designs
Fabric Design		S-47		S-4
Monopro 33				0.6
Monopro HTR, Monotop HTR		0.7
Monosoft		0.7		0.6

Spiral Designs
Fabric Design		Spiral
SpiralTec, SpiralFine, SpiralPro		0.6
SpiralDry		0.7

Transport Fabric Designs
Fabric Design		S-U		S-IC
TransporTier III C(S)		1		1.2
MonoTransport C				1.2

* All wire diameters in mm

Seam Strength



MonoTier Concept Fabric Designs
						PPS edge reinforcement
Fabric Design	CFM	S-4 HP	S-47 HP	S-47 k	S-43	S-4 HP	S-47 HP
MonoTier II R	80-200	750	600
MonoTier II R-6	120-200	750	600			550	600
UltraClean R & PermaLife II	80-200	750
MonoTec	80-200	800
MonoTec	250-400	600	800
MonoTier III R	150-400	750	750
MonoTier III R-6 & R-6 Plus	150-400	750	750			500	600
MonoTier III R	500-600		750	550	550
MonoTier III R-6 & R-6 Plus	500-600		750	550	550		750
UltraTier II & UltraTemp	120-200	550	600			550	600
UltraTier II, II-6 & UltraTemp	250-400	450	650			450	650
UltraTier III	500-600		600	550	550

Smart Surface Technology Fabric Designs
						PPS edge reinforcement
Fabric Design	CFM	S-4 HP	S-47 HP	S-47 k	S-43	S-4 HP
MicroTec II	80-200	800
MicroTec II-6	120-200	800				550
MicroTec II	250-400	600	800			600
MicroTec II-6	250-400	600	800			450
CleanTec II & SpeedTec II	110-200	800
CleanTec II	250-350	600	800
MagnaTec	110-200		600	450	650

Conventional Fabric Designs
Fabric Design		S-47			S-4
Monopro 33		500			500
Monosoft		500			500
Monopro HTR, Monotop HTR		500

* Seam Strength [daN/10 cm]

Poles



FABRIC SIZE
		FABRIC WIDTH (m)
MINIMUM LENGTH (m)		≤ 4.8	> 4.8	>5.8	> 7.5	> 10
MAXIMUM LENGTH (m)		≤ 4.8	≤ 5.8	≤ 7.5	≤ 10	≤ 12
≤ 30	Pole Ø (mm)	C* 168	C* 168	139,7	139,7	139,7
	Extra Length (cm)	20	20	60	60	60
	Thickness (mm)	14	14	3	3	3
> 30 ≤ 40	Pole Ø (mm)	C* 168	139,7	139,7	139,7	168,3
	Extra Length (cm)	20	60	60	60	60
	Thickness (mm)	14	3	3	3	5
> 40 ≤ 50	Pole Ø (mm)	139,7	139,7	139,7	168,3	168,3
	Extra Length (cm)	60	60	60	60	60
	Thickness (mm)	3	3	3	5	5
> 50 ≤ 60	Pole Ø (mm)	139,7	139,7	168,3	168,3	219,1
	Extra Length (cm)	60	60	60	60	60
	Thickness (mm)	3	3	5	5	4
> 60 ≤ 75	Pole Ø (mm)	139,7	139,7	168,3	219,1	219,1
	Extra Length (cm)	60	60	60	60	60
	Thickness (mm)	3	3	5	4	4
C* = cardboard pole

PACKAGING
The rolled up fabrics are protected against damages by several layers of different materials, which are as follows: • plastic foil (black) • 2 half core protecting shells (adapted to roll diameter) Exception : if the diameter is bigger than the biggest (50 cm) existing half core protecting shells, the fabric will be packed in a wooden box. Each packaging is furthermore fastened with reinforced synthetic ribbons (about every 50 cm) which are easy and safely to open with a knife.

JOINING WIRES
In each dryer fabric packaging there are added 2 joining wires (one spare joining wire). Each joining wire is packed into a SAF-T-JOIN container to protect it against damage and to unroll easy.

FILLING WIRES
^# to reach same permeability in the warp loop area and the fabric.




^# on request for MonoTier Concept dryer fabrics with S-4 HP seam.

Options



	COLOURED STEEL WIRE TIP
		COLOURED STEEL WIRE TIP for better visibility during seam joining.


	SEAMING TOOL
		SEAMING TOOL for all AstenJohnson spiral fabrics.


	CHEMICAL TREATMENTS
		ARMORTEC° oleophobic and hydrophobic nanocoating to improve cleaning properties of MicroTec dryer fabrics in relation with cleaning installations.
	HYDROPHOBIC EXAMPLE


	OLEOPHOBIC EXAMPLE


	STRIPES IN CONTRASTING COLOURS*
		(for optical detection systems) Not available for all fabric designs. Information : Product Manager. Please define clearly the position of the stripes (front side, driven side, x cm from the edge, width, on paper side and/or back side). No individual orders. Order minimum by pairs.





		* on request + standard for spiral fabrics ° on request for MicroTec

Edge Protections



EDGE PROTECTIONS
	NAME	DESCRIPTION
PROLINE S		Elastic edge protection processing with monofilament melting and sealing with a high performance Acrylic Polymer. Width : 35 mm. Standard on MonoTier Concept dryer fabrics.
PROTEC S*		Elastic edge protection processing with ultrasonic welding, monofilament melting and sealing with a high performance Acrylic Polymer. Width : 35 mm. Thanks to the diagonal ultrasonic welding of machine direction and cross machine direction threads, the necessary elasticity of the fabric edges is guaranteed under any conditions.
CERAN II*
	CERAN II* edge protection processing with ultrasonic welding, monofilament melting and sealing with a hot-melt adhesive. \Width : 20 mm.


HMC*
	HMC* edge protection processing with monofilament melting and sealing with a hot-melt adhesive. Width : 20 mm.


PU+
	PU⁺ edge protection processing with monofilament melting and sealing with a high temperature resistant PU glue. Width : 30 mm. Only available on spiral fabrics.


VR*
	VR* edge protection processing with monofilament melting of warp and weft yarns.



SPECIAL REMARKS
	For dryer fabrics ≤ 15 m length, only the edge protections CERAN II, HMC and VR are available.
	For positions where the fabric tension is below 1.5 kg/cm, the edge protections Ceran II, HMC and VR are available.
	* on request + standard for spiral fabrics

Edge Reinforcement



HYDROLYSIS RESISTANT EDGE REINFORCEMENT*
	• Standard width : 30 cm. • Minimum fabric width : 3 m. • No individual orders. • Order minimum by pairs.










FABRIC TOLERANCES
	LENGTH (ordered length to delivered length without tension) :
		≤ 20 m	± 15 cm
		≤ 40 m	± 20 cm
		≤ 60 m	± 25 cm
		> 60 m	± 30 cm

		WIDTH :	± 1 cm

AIR PERMEABILTY TOLERANCES (cfm at 125 Pa)
		Range	Woven Fabrics	Spiral Fabrics
		≤ 120 cfm :	± 10 cfm	± 15 cfm
		125-200 cfm :	± 25 cfm	± 25 cfm
		205-550 cfm :	± 50 cfm	± 50 cfm
		600-1000 cfm :	± 100 cfm	± 100 cfm
	Conversion Factor Measuring Unit Air Permeability cfm 0.5 inch = m/h 100 Pa / 16,3. m³/(m².h) is shortened to m/h. ft³/(ft².min) is shortened to cfm.
	* on request
